Two black fastening wing nuts with stud arranged on a neutral background.

FASTENING KNOB WITH STUD

material: glass fiber reinforced nylon 6

standard color: black

insert: galvanized stud
on request: other colors and stainless steel stud

DOWNLOAD TECHNICAL DATA SHEET

CODICE / CODE __ (+I)	TIPOLOGIA / TYPE	D	L	b	l1	l2	d1	d	__l	PESO / WEIGHT G	DOWNLOAD
GALPZ00NFN34M5_ _	GF/34 M5X10	33,5	18,5	6,5	17	4	14	M5	10 / 15 / 20 / 25 / 30	7,2	MONPLAST_GALLETTO_D33,5_M5_PERNO download file step .zip Send download link to:
GALPZ00NFN34M6_ _	GF/34 M6X10	33,5	18,5	6,5	17	4	14	M6	10 / 15 / 20 / 25 / 30	8,8	MONPLAST_GALLETTO_D33,5_M6_PERNO download file step .zip Send download link to:
GALPZ00NFN34M8_ _	GF/34 M8X10	33,5	18,5	6,5	17	4	14	M8	10 / 15 / 20 / 25 / 30	9,1	MONPLAST_GALLETTO_D33,5_M8_PERNO download file step .zip Send download link to:
GALPZ00NFN48M6_ _	GF/48 M6X10	47,5	20	6	18	4	17	M6	10 / 15 / 20 / 25 / 30 / 35 / 40 / 45	10,2	MONPLAST_GALLETTO_D47,5_M6_PERNO download file step .zip Send download link to:
GALPZ00NFN48M8_ _	GF/48 M8X10	47,5	20	6	18	4	17	M8	10 / 15 / 20 / 25 / 30 / 35 / 40 / 45	11,3	MONPLAST_GALLETTO_D47,5_M8_PERNO download file step .zip Send download link to:

REQUEST A QUOTE

I would like to receive more information about Monplast products.
Fill out the form, and we will get back to you as soon as possible.

handles hinges feet levers handwheels grips wing knobs caps spring plungers and indexing pins
